Cannondale Moterra Neo Carbon Suspension Link

Cannondale Moterra Neo Carbon Yoke Medium 60mm

Cannondale Moterra Neo Yoke Large / XLarge 90mm

Cannondale Moterra Neo Link /Chain Stay / Seat Stay Pivot Hardware

Cannondale Moterra Neo / Habit Upper Shock Bolts

Cannondale Moterra Link / Chain Stay / Seat Stay Pivot Bearings

Cannondale Moterra Neo / Habit Yoke Bolts with Shims

Cannondale Moterra Down Tube Battery Rail, Bottom Exit

Cannondale Moterra Alloy, Rail Cable Guides - Qty 4

Cannondale Battery Cover DT Bottom Exit 750wh (MY22+ Trail Neo, Moterra Neo)

Cannondale Moterra Neo Latching Charge Port Holder

Cannondale Moterra Neo Down Tube Cable Guide

Cannondale Moterra Motor Mounting Bolts - Quantity 8

Cannondale Moterra Generation 4 Drive Unit Skid Plate

Cannondale Moterra Motor Mounting Bolt Cover

Cannondale 1.8" Internal Headset 28.6/52-60/45.83. Suit 2022+ Moterra

Cannondale Moterra Carbon Head Tube Internal Routing Sleeve 1.8

Gallery
Description

Description

Moterra Neo Carbon Bosch 2022+ Spares

Drive System - Bosch Performance Line CX
Battery - Bosch PowerTube 750Wh
Rear Travel - 150mm
Head Tube - UPR: 1-1/2” LWR: 1.8”
Headset - ACROS 1.5-1.8 Integrated w/Internal Cable Routing K35012 1.5-1.8 Int Hdset 28.6/52 - 60/45.83
Bottom Bracket: Type / Width - Bosch Drive Unit
Front Derailleur - N/A
Seat Post: Dia./Binder - 31.6mm/34.9mm
Min. Seat Post Insert - 100 mm
Max. Frame Seat Post Insert Depth - SM: 235mm MD: 260mm LG-XL: 280mm
Tire Size x Max. Width - SM FT: 29 x 2.6” SM RR: 27.5 x 2.6”, MD-LG FT+RR: 29 x 2.6”
Max. Fork Length - 583mm
Rear Shock: Eye-to-Eye / Stroke / Bushing Width - 230mm COIL / 60mm / Frame: M8 x 20mm Yoke: N/A
Sag - 25% / 15mm
Chain Guide - e*thirteen CG3UPM-100 Bosch Gen4
Brakes: Mount Type/Min/Max Rotor Diameter - Post Mount / 180mm / 220mm
Axles: Type/Length - Maxle UDH 148mm, M12x1.0P, 180mm Overall Length
Max. Weight Limit: Total - 138kg

Cannondale Moterra Neo Carbon Bosch 2022+ Spares

$329.00

Tax included. Shipping calculated at checkout

SKU:
FRCAK91002
BRAND:
Cannondale

Select stock item

Product variants

Please note that some dropdown options are parts only. Please choose carefully.

FAST SHIPPING

14 DAY RETURNS

EXPERT SUPPORT

Note on Availability Items available on our website are not always available in-store, some are only held by our suppliers. In-store items usually arrive 2-3 business days after the order is dispatched(rural deliveries can take an extra 2 business days). Items only held with supplier might take up to 7 business days from when the order is dispatched, depending on the supplier. Please contact us if you have specific questions.

Description

Moterra Neo Carbon Bosch 2022+ Spares

Drive System - Bosch Performance Line CX
Battery - Bosch PowerTube 750Wh
Rear Travel - 150mm
Head Tube - UPR: 1-1/2” LWR: 1.8”
Headset - ACROS 1.5-1.8 Integrated w/Internal Cable Routing K35012 1.5-1.8 Int Hdset 28.6/52 - 60/45.83
Bottom Bracket: Type / Width - Bosch Drive Unit
Front Derailleur - N/A
Seat Post: Dia./Binder - 31.6mm/34.9mm
Min. Seat Post Insert - 100 mm
Max. Frame Seat Post Insert Depth - SM: 235mm MD: 260mm LG-XL: 280mm
Tire Size x Max. Width - SM FT: 29 x 2.6” SM RR: 27.5 x 2.6”, MD-LG FT+RR: 29 x 2.6”
Max. Fork Length - 583mm
Rear Shock: Eye-to-Eye / Stroke / Bushing Width - 230mm COIL / 60mm / Frame: M8 x 20mm Yoke: N/A
Sag - 25% / 15mm
Chain Guide - e*thirteen CG3UPM-100 Bosch Gen4
Brakes: Mount Type/Min/Max Rotor Diameter - Post Mount / 180mm / 220mm
Axles: Type/Length - Maxle UDH 148mm, M12x1.0P, 180mm Overall Length
Max. Weight Limit: Total - 138kg
