FLOW SMART
The Flow Smart offers all the necessary features you need for a fully interactive indoor cycling experience. It connects to most popular training apps, like Zwift, Tacx and Trainerroad. And its wheel-on design allows for easy setup and storage. This trainer is the perfect winter training tool.
ACCURATE - Measures your power accurately within 2,5%.
SECURELY LOCKED IN - Tacx wheel-on trainers are easy to setup. With two easy clicks your bike is securely locked in the trainer frame, making sure that your bike is safely fixed and doesn’t go anywhere.
DUAL MATERIAL ROLL - The roll is made from two materials: a hardened steel sleeve with a soft core of elastogel. The steel sleeve prevents wear of the trainer, while the elastogel absorbs vibrations to reduce noise.
SKYLINER AS A HANDLE - The Skyliner not only serves as a front wheel support for a natural cycling position, but can also be used as a handle for your trainer.
STABLE FRAME - Designed with a large footprint and strong materials, this bike trainer is able to withstand the most intense training sessions.
FEATURES & SPECIFICATIONS
FEATURES
Type of trainer Interactive Smart direct drive with electric brake
Magnets 6 magnets
Transmission Roller 30mm
Electrical requirements 110-240 Volt
Power indicator None
Connection indicator None
Firmware upgradable Yes
Suitable cassettes Shimano & SRAM: 8 - 11 speed. Campagnolo body sold separately
Suitable axles Width of rear fork: Race 130 mm, MTB 135 mm. Adapters for other widths available
Suitable bikes Race, Tri & MTB if necessary with axle skewer , 29ʺ wheel with Tacx trainer tyre
Supplied with Front wheel support , Quick release for road bikes and mountain bikes (5mm)
SPECIFICATIONS
Max. power (40 km/h) 800 Watt
Max. incline 6%
Simulation of descent No
Max. torque 15.3Nm
Max. brake force 45 N
Flywheel Actual of 1.6 kg
Mass inertia 11.8kg (26.0 lbs)
Calibration Spin down
Footprint (lxw) 675 × 650 mm (26.6 × 25.6 in)
Height 410 mm (16.1 in)
Dimensions 565 × 410 × 245 mm (22.2 × 16.1 × 9.65 in)
Weight 9.41 kg (20.7 lbs)
Article number T2240
DATA OUTPUT AND CONTROL
Wireless communication ANT+ FE-C , Bluetooth Smart open
Control by ANT+FE-C bike computers , Connect to computer via ANT+antenna , Smartphone , Stand alone , Tablet
Output Cadence , Power , Speed
Read out on Bike computer , Computer with ANT+ antenna , Smartphone , Sports watch , Tablet
Accuracy <5
