The perfect quick-mount rear rack system attaches to road, cross, hybrid or touring bike seatstays. This one-size-fits-all rear rack features an innovative top plate that adjusts to level independent the seatstay angle. Integrated QuickTrack® system allows Topeak TrunkBags to slide and lock into place and release with a the push of a button. Innovative hook and loop strap mounting system cinches down tight to keep the load stable and allow mounting on a wide range of bikes.
NOTE: TetraRack is not recommended for carbon forks and seat stays. TetraRack series racks are not compatible with front or rear mounted V-Brake type systems.
- Strut slot adjustments allow the rack top plate to be level independent of the seatstay angle
- Adjustable straps with padded feet securely attach rack to seat stays
- Compatible with Topeak QuickTrack® system bags
- Clamp for rear reflector
- TetraRack has a mounting length of 200mm.
- Seatstays and front forks must not contain any obstacles that prevent mounting TetraRack securely.
- Seatstay diameter must be larger than 15mm.
- It is not recommended to mount TetraRack R2 on carbon frames.
- Compatible with seatstays width within 75-105mm. Ensure not to exceed max weight capacity. (9kg / 20lb)
| ATTACHMENTS | Seatstays with hook and loop straps |
| ADJUSTMENT | Strut slots |
| MATERIAL | Aluminum / Engineering grade polymer / Nylon straps |
| COMPATIBILITY | Topeak MTX / RX TrunkBags |
| MAX LOAD | 9 kg / 20 lb |
| ADDED FEATURE | Clamp for rear reflector, Tail Light Mount |
| SIZE | 39.5 x 30 x 12 cm / 15.6” x 11.8” x 4.7” |
| WEIGHT | 870 g / 1.92 lb |
