Description

Carbon Road Performance for Everyday Riding

The X-LAB RS7 is a carbon road bike for riders who want responsive performance, dependable components and a bike they can enjoy on regular road rides. Its carbon frame and fork, Shimano 105 12-speed mechanical drivetrain, Branta power meter and carbon wheels make it a well-equipped choice for bunch rides, training and longer days out.

In Angel Wing White, the RS7 has a performance-focused riding position and 32 mm tyres that make sense on the coarse chip seal found on many New Zealand roads.

Toray T700 Carbon Frame and Fork

The XDS frame and fork use Toray T700 carbon, providing a responsive foundation for climbing, accelerating and faster road riding. The RS7 is designed for riders who want performance without necessarily choosing the lowest position of a dedicated aero race bike.

An aero-profile carbon seatpost and integrated carbon cockpit give the bike a tidy finish. The claimed complete-bike weight is 8.49 kg in size L.

Dependable Shimano 105 Shifting

Shimano 105 mechanical shifting is a practical choice for regular riding. The 2 × 12-speed drivetrain gives you plenty of gears to work with, while cable-operated shifting means there are no derailleur batteries to charge.

The 52/36T chainrings suit faster road riding, and the 11–34T cassette provides a useful lower gear for longer climbs. If you are new to road riding or regularly tackle steep hills, talk to us about whether the gearing will suit your routes.

Power Meter and Apple Find My

The Branta alloy crankset includes a power meter, allowing you to measure effort, follow structured workouts and pace longer rides without buying a separate unit.

Apple Find My compatibility is also integrated into the crankset. It can help locate the bike through a compatible Apple device and account, but it does not replace a quality physical lock when the bike is left unattended.

Branta C45 Base Carbon Wheels

The Branta C45 Base carbon wheelset is a worthwhile inclusion for riders who want carbon wheels from the start. Stainless-steel spokes provide a practical approach to maintenance, while the wheelset complements the RS7’s performance-focused build.

Branta R332 700 × 32C tyres provide useful air volume for comfort and grip on coarse chip seal and uneven roads. Check the compatibility of the rims and tyres before changing to a tubeless setup.

Shimano 105 Hydraulic Brakes

Shimano 105 hydraulic disc brakes provide controlled stopping in changing weather. The supplied specification lists Shimano SM-RT70 160 mm rotors front and rear, a practical combination for everyday road riding and longer descents.

Integrated Carbon Cockpit

The Branta integrated carbon handlebar and stem keeps the front of the bike tidy. Stem length and handlebar width vary by frame size, so check the measurements below before ordering.

Changing the reach or bar width on a one-piece cockpit may require replacing the whole unit. If you already have a road position that works well, bring us your measurements and we can help compare them with the RS7.

Key Features

  • XDS Toray T700 carbon frame and fork
  • Shimano 105 mechanical 2 × 12-speed shifting
  • Shimano 105 hydraulic disc brakes
  • Branta alloy power-meter crankset
  • 52/36T chainrings and 11–34T cassette
  • Apple Find My compatibility integrated into the crankset
  • Branta C45 Base carbon wheels
  • Stainless-steel spokes
  • Branta R332 700 × 32C tyres
  • Branta integrated carbon handlebar and stem
  • XDS aero-profile carbon seatpost
  • Threaded BSA bottom bracket
  • Angel Wing White finish
  • Claimed weight: 8.49 kg in size L

Who Is It For?

  • Fast recreational road riding
  • Weekend bunch rides
  • Longer road events
  • Structured training with power
  • Riders upgrading from an aluminium road bike
  • Riders who prefer mechanical shifting
  • Riders wanting carbon wheels from the outset
  • Riders who value comfort alongside speed

The RS7 is a performance road bike. Riders looking for a particularly upright position or a bike for regular unsealed riding may be better suited to an endurance or gravel model.

Our Thoughts

The RS7 has a sensible mix of performance and practical equipment. Shimano 105 mechanical shifting is straightforward to maintain, while the power meter and carbon wheels are parts many riders would otherwise look at adding later.

The 32C tyres are a good choice for New Zealand roads, where coarse chip seal can make a narrow-tyred bike feel harsh. For regular road rides, training and faster weekends with friends, this is a well-equipped package.

We would check the integrated cockpit dimensions before choosing a size. Getting the right reach and handlebar width will make more difference to your comfort than saving a few grams elsewhere.

Technical Specifications

Frameset

  • Frame: XDS carbon, Toray T700
  • Fork: XDS carbon, Toray T700, 12 × 100 mm front thru-axle
  • Seatpost: XDS carbon, aero profile
  • Bottom bracket: BSA threaded, 24 mm

Drivetrain

  • Shifters: Shimano 105 ST-R7120, mechanical 12-speed
  • Front derailleur: Shimano 105 FD-R7100
  • Rear derailleur: Shimano 105 RD-R7100
  • Cassette: CS-R9012, 12-speed, 11–34T
  • Crankset: Branta alloy power-meter crankset, 24 mm steel spindle
  • Chainrings: 52/36T
  • Chain: SUMC SX12
  • Security technology: Apple Find My compatibility

Brakes

  • Brakes: Shimano 105 BR-R7170 hydraulic disc
  • Rotors: Shimano SM-RT70, 160 mm front and rear

Wheels and Tyres

  • Wheelset: Branta C45 Base carbon
  • Spokes: Stainless steel
  • Tyres: Branta R332, 700 × 32C, 60 TPI

Cockpit and Contact Points

  • Handlebar and stem: Branta integrated carbon
  • Seatpost: XDS carbon, aero profile
  • Saddle: Branta R302 with steel rails

Sizes, Colour and Weight

  • Sizes: XS, S, M, L, XL and XXL
  • Colour: Angel Wing White
  • Claimed weight: 8.49 kg in size L

Size Guide

  • XS: 148–158 cm
  • S: 158–168 cm
  • M: 168–176 cm
  • L: 176–183 cm
  • XL: 183–191 cm
  • XXL: 191–202 cm

Rider height is a starting point only. Body proportions, flexibility and preferred riding position all affect the best size. Contact Chain Reaction for help comparing the geometry and cockpit dimensions before ordering.

Size-Specific Components

Size Stem Handlebar Crank Seatpost
XS 90 mm 360 mm 165 mm 300 mm
S 100 mm 360 mm 165 mm 300 mm
M 110 mm 380 mm 170 mm 350 mm
L 110 mm 380 mm 170 mm 350 mm
XL 120 mm 400 mm 172.5 mm 400 mm
XXL 120 mm 400 mm 172.5 mm 400 mm

Geometry

All lengths are in millimetres unless otherwise stated.

Measurement XS S M L XL XXL
Seat-tube length 420 440 470 490 510 530
Top-tube length 500 515 531 550 570 590
Head-tube length 130 135 145 160 175 200
Seat-tube angle 75° 75° 75° 74° 74° 74°
Head-tube angle 70° 72° 73° 73° 73° 74°
Chainstay length 410 410 410 410 410 410
Wheelbase 973 976 982 993 1,006 1,016
Fork offset 55 55 45 45 45 45
Bottom-bracket drop 72 72 70 70 68 68
Stack 526 535 546 561 574 602
Reach 360 370 380 390 400 412
Front centre 574 577 581 593 606 616
Standover height 737 752 772 789 807 830
Trail 65 58 62 60 58 52

Why Buy from Chain Reaction?

  • Professionally assembled, tuned and safety checked
  • Brakes professionally checked and bedded in
  • Gears adjusted and drivetrain tuned
  • Power meter setup and pairing assistance
  • Expert road-bike sizing and setup advice
  • Initial cockpit and saddle setup
  • Practical maintenance advice at handover
  • Finance and WorkRide options available

Visit Chain Reaction at 4/218 Moorhouse Avenue, Christchurch. There are more than 200 free car parks on-site, along with room to discuss sizing and setup.

Specifications are based on supplier information and may change without notice. Claimed weight is for a size L bike and may vary with frame size, finish and production components.
